Frame Rates |
70.. 255 FPS (Hz)
|
Display method |
Switching SBS
|
Connection |
Bluetooth LE
|
Lens polarization |
+45 degrees
|
Power Source |
5V USB
|
USB Connector |
USB2 Micro-B
|
Battery |
LiPo 3.6V 55mA/h
|
Charging time |
~1...3 hours
|
Continuous work |
~6 hours
|
Operation system |
Win7... Win11 x86, x64
|
Glasses High Resolution Images
Manual Control
The glasses have 4 control buttons.
You can change the player settings remotely via Bluetooth connection.
1. To turn
On, press any button.
2. To turn
Off, press and hold the
"Power" button.
3. To remotely switch the perspective
R/L, press button
"A".
4. To remotely adjust the
Offset -, press button
"B".
5. To remotely adjust the
Offset +, press button
"C".
Firmware Update
The softwares inside S3D Glasses are sufficiently complex and there are still
plenty of hidden bugs. We periodically find and fix them, and improve functionality.
You can download the new firmware file yourself.
Use the DFU updater App to fill file to device.
To update firmware do the following steps:
1. Disconnect the Glasses from the computer
2. Close Player. Open DFU application
3. Connect the Glasses to computer
4. Click the line with the device name
5. Select the firmware by the File button
6. Press the Prog button and wait for done
7. Launch new firmware by clicking Run
In rare cases, the firmware may program with an errors and the
glasses hang up. The error may occur if you pull out the cable during programming.
To exit from freeze and force jump to the update mode,
press and hold the A+B buttons. If that doesn't work either, briefly short
the battery with tweezers and then connect the USB power cable.
